Vition Plate Heat Exchanger Parts S21A Thermodynamically Optimized Design

China Jiangyin M&C Heat Parts Co.,Ltd certification
I'm Online Chat Now

Vition Plate Heat Exchanger Parts S21A Thermodynamically Optimized Design

Vition Plate Heat Exchanger Parts S21A Thermodynamically Optimized Design
Vition Plate Heat Exchanger Parts S21A Thermodynamically Optimized Design Vition Plate Heat Exchanger Parts S21A Thermodynamically Optimized Design Vition Plate Heat Exchanger Parts S21A Thermodynamically Optimized Design Vition Plate Heat Exchanger Parts S21A Thermodynamically Optimized Design

Large Image :  Vition Plate Heat Exchanger Parts S21A Thermodynamically Optimized Design

Product Details:
Place of Origin: Jiangsu, China (Mainland)
Brand Name: M&C
Certification: ISO SGS FDA
Model Number: S21A
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: Standard Export Carton,Wooden Case,Plywood
Delivery Time: 5-8 work days
Payment Terms: L/C, D/P, T/T, MoneyGram
Supply Ability: 50000PCS/MONTH
Detailed Product Description
Product Name: Plate Heat Exchanger Parts Material: Rubber,NBR,EPDM
Structure: Plate Heat Exchanger Application: Liquid To Liquid Heat Exchanging
Dimension: Centre To Centre: 719mm*225mm Transfer Area: 0.21㎡
Highlight:

epdm rubber gasket

,

marine heat exchanger gaskets



Basic information of gasket



Plate heat exchanger gasket is one of the important parts of plate heat exchanger, which can produce plastic deformation and have certain strength.

M&C's gaskets are customized to fit the customer's working conditions and are manufactured by a professional factory in a specified size.

The contact width between the high pressure gasket and the sealing surface is very narrow (line contact).

Sealing principle:

The corrugated plate is pasted with sealing gasket, which is designed to double seal structure and has signal hole.When the medium leaks from the first seal, it can leak out from the signal hole, and the problem can be detected and solved as soon as possible, without causing the mixing of the two media.Sealing gasket according to different media and operating temperature to choose different types of gaskets.



Product information



Brand name:M&C

Material:NBR,EPDM

Advantage: produce plastic deformation and have certain strength.



Feature



A: Simple style and good sealing

B: Widely used and adaptable

C: Resistant to corrosion and high temperature

D: Easy to disassemble and maintain



Parameters



Gasket Material Temperature Range(℃) Hardness Available Fluid
NBR -20 to 110 -75+/-3 Water,Oil,Acid etc
EPDM -30 to 150 80+/-5 Steam,Ammonia,Acid etc
NBR-HT -30 to 160 85+/-5 Mineral Oil,Thermal Oil
EPDM-HT -30 to 180 85+/-5 High-Temperature Water
TFEP -20 to 180 80+/-5 Acid,Glycol,Chloride
FPM -55 to 220 80+/-5 Acid,Glycol,Chloride

Vition Plate Heat Exchanger Parts S21A Thermodynamically Optimized Design 0



Application



Application:HAVC, Powerplant, Food, Marine, Refinery, Pharmace, Mining, Chemical, Refrigeration



Why choose us ?



1. We always think from the perspective of customers, solve problems and bring higher value to customers

    2. More than 15 years of professional experience and expert team

3. Professional production r&d team to improve heat exchange efficiency and reduce operating costs

    4. The technical scheme of guaranteed commitment

    5. Whole process service from pre-sale to after-sale

    6. Help customers reduce risks and save costs to maximize customer benefits

Vition Plate Heat Exchanger Parts S21A Thermodynamically Optimized Design 1
